| Pressure resistance: | 5、10、15 bar | |||||||||
| Medium temperature: | -40～80℃（-40～200℃） | |||||||||
| Media Density: | ≥0.75g/cm³ | |||||||||
| Media Density: | 0.75kg/cm³ | |||||||||
| output: | Contact Type: Reed Switch | |||||||||
| Contact capacity: 230VAC, 0.5A | ||||||||||
| Output: normally open/normally closed optional | ||||||||||
| Protection class: | IP67 | |||||||||
| Wiring: | direct double line | |||||||||
| Material: | Stainless steel (PP plastic) | |||||||||
| Electrical life: | 100000000 times | |||||||||
| model | signal type | Dimensions (Material: Stainless Steel) | ||||||
| L | float code | d1 | H | d2 | M | h | ||
| LV-Mini61-46NO （*） | Normally open | 46.0 | FS02 | Φ28.6 | 28.0 | Φ8.0 | M10×1.0 | 26.0 |
| LV-Mini61-46NC （*） | Normally closed | 46.0 | FS02 | Φ28.6 | 28.0 | Φ8.0 | M10×1.0 | 26.0 |
| LV-Mini61-187NO | Normally open | 187.0 | FS01 | Φ25.4 | 24.5 | Φ8.0 | M10×1.0 | 170.0 |
| LV-Mini61-187NC | Normally closed | 187.0 | FS01 | Φ25.4 | 24.5 | Φ8.0 | M10×1.0 | 170.0 |
| LV-Mini61-349NO | Normally open | 349.0 | FS02 | Φ28.6 | 24.5 | Φ8.0 | M16×2.0 | 320.0 |
| LV-Mini61-349NC | Normally closed | 349.0 | FS02 | Φ28.6 | 28.0 | Φ8.0 | M16×2.0 | 320.0 |
| Float code (stainless steel) | float size | weight | proportion | Pressure resistance | Operating temperature | Applicable media | material |
| Outer diameter*height*inner diameter | g | （G / cm3) | kg/cm2 | °C | |||
| FS02 | Φ28.6*28*Φ9.5 | 8.4 | 0.7 | 15 | -40~+200 | Water, oil, weak acid and alkali | 316L |
| FS01 | Φ25.4*24.5*Φ9.5 | 6.2 | 0.82 | 10 | -40~+200 | Water, oil, weak acid and alkali | 304 |
Remarks: The above switches are low-power dry reed switches. Signal contact capacity: 230VAC, 0.5A; if you need high power or high current higher than this standard, please consult the remarks order before ordering.
